Kibra DDR Protocol Analyzer User Manual 71
CrossSync Control Panel Teledyne LeCroy
Figure 2.41: Analyzer Devices Dialog
In the current version of the DDR Protocol Suite up to four devices are supported with the
CATC_Sync cable.
For more information on Devices refer to “Launching Your Kibra 380 or Kibra 480
Software” on page 24 .
2.8 CrossSync Control Panel
The CrossSync Control Panel allows you to select multiple types of Teledyne LeCroy
Protocol Analyzers for synchronization and manage the recording process.
2.8.1 Launching the CrossSync Control Panel
To launch CrossSync from the Kibra 380 Protocol Analyzer or Kibra 480 DDR4 Protocol
Analyzer software application, select the ‘Launch CrossSync Control Panel‘ in the Setup
menu (see the screen below). Or, you can launch CrossSync from the ‘Start’ menu.
Figure 2.42: Launching CrossSync from the Kibra 380 Protocol Analyzer Application
Please refer to the CrossSync Control Panel User Manual for more information.
