Teledyne LeCroy Launching Your Kibra 380 or Kibra 480 Software
24 Kibra DDR Protocol Analyzer User Manual
1.7 Launching Your Kibra 380 or Kibra 480 Software
To launch the software, double‐click the DDR Protocol Suite Icon in the Program
Manager Window, or select DDR Protocol Suite from the Start > Programs >LeCroy
menu. The following screen displays. The Device Bar has the following panes as shown in
the following figure.
1. Device: Shows attached device by Serial Number
2. Quick Recording Options: Enables Trigger and Buffer settings
3. Recording Control and Status: Start, Stop and Pause recording and view status.
4. Real Time Statistics: View the statistics while recording.
Figure 1.10: Main Screen
1 2 3 4
