Teledyne LeCroy Installing Your Kibra 380 or Kibra 480 Protocol Analyzer
14 Kibra DDR Protocol Analyzer User Manual
1.3 Installing Your Kibra 380 or Kibra 480 Protocol Analyzer
Software Installation
The software works on systems using the Windows
®
XP, Windows 8, and Windows 7 32‐
or 64‐bit operating systems.
1. Insert the Installation CD‐ROM into the CD drive on the host machine.
2. The installation automatically starts setup, unless Auto Run is off. In that case, select
the CD‐ROM from “My Computer” and click Setup.
3. After the warning to close all other programs and before starting the installation,
the Install component selection opens.
4. Select components for installation.
5. Click Next to complete the installation.
System Restart
It is recommended that you restart your host machine before you use your Analyzer
software.
Error Message
If you get an error message during installation of the drivers for Window, consult your
system administrator. Your system may allow only administrator‐level users to copy such
driver files.
1.4 Hardware Setup
1.4.1 Connecting in General
Note: You must install the software before connecting the analyzer to the host machine for the first
time.
To set up the analyzer:
1. Connect the analyzer to a 100V–240V, 50Hz–60Hz, power outlet, using the supplied
12‐volt power brick, and turn on the Power switch.
At power on, the analyzer will go through initialization as shown on the application
screen.
2. Connect the USB cable between the Kibra 380 or Kibra 480 and a USB port on the
host machine. The host machine’s operating system detects the analyzer and driver
files.
