Teledyne LeCroy Traffic Summary
140 Kibra DDR Protocol Analyzer User Manual
The Traffic Summary View for each captured signal
Traffic Summary - Commands
A summary of the Commands can be viewed on this page (see Figure 3.53). You can view
Command in Ranks, Command in Banks, MRS Commands or Register Control
Commands.
Figure 3.53: Traffic Summary - Commands
Figure 3.54: Traffic Summary - Commands in Ranks
Select Ranges. Select the range of time for the reports to cover.
Print. Print on a Printer.
