1.4.1 PIO Input and Output Interface
Input Section
Output Section
6SHFL¿
cation
Input Voltage
24V DC
r10%
Load Voltage
24V DC
Input Current
4mA 1circuit
Peak Load Electric
Current
50mA/1circuit
ON/OFF Voltage
ON Voltage MIN.18V DC
OFF Voltage MAX.6V DC
Leakage Current
MAX.0.1mA/1point
NPN
680
5.6K
P24
External
Power Supply
24V DC
Controller
Internal
Power Supply
Input
Terminal
Controller
22
P24
0
Load
External
Power Supply
24V DC
Internal
Power Supply
Output
Terminal
PNP
Controller
680
5.6K
0
External
Power Supply
24V DC
Internal
Power Supply
Input
Terminal
Controller
Load
22
P24
0
External
Power Supply
24V DC
Internal
Power Supply
Output
Terminal
I/O
Cable
Refer to 2.1.3 Circuit Diagram
0V
24V
NPN Type
Pin No.
1
2
3
4
5
6
7
8
9
10
Load
24V
0V
PNP Type
Pin No.
1
2
3
4
5
6
7
8
9
10
Load
