4.
Appendix
Actuator
series
Type
Feed
screw
Motor
output
No. of
encoder
pulses
Lead Mounting
direction
Minimum
speed
Maximum speed
Maximum acceleration/
deceleration
Minimum
push
force
Maximum
push
force
Rated
push
speed
[W] [mm] [mm/s] [mm/s] [G] [N] [N] [mm/s]
RCA2
(slider
type)
SA3C
Ball
screw
10 800
6
Horizontal
7.5 300
0.3 - - -
Vertical 0.2 - - -
4
Horizontal
5 200
0.3 - - -
Vertical 0.2 - - -
2
Horizontal
2.5 100
0.2 - - -
Vertical 0.2 - - -
SA3R
Ball
screw
10 800
6
Horizontal
7.5 300
0.3 - - -
Vertical 0.2 - - -
4
Horizontal
5 200
0.3 - - -
Vertical 0.2 - - -
2
Horizontal
2.5 100
0.2 - - -
Vertical 0.2 - - -
SA4C
Ball
screw
20 800
10
Horizontal
12.5
380 (at 50st)
500 (at 100 to 500st)
0.3 - - -
Vertical 0.2 - - -
5
Horizontal
6.25 250
0.3 - - -
Vertical 0.2 - - -
2.5
Horizontal
3.12 125
0.2 - - -
Vertical 0.2 - - -
SA4R
Ball
screw
20 800
10
Horizontal
12.5
380 (at 50st)
500 (at 100 to 500st)
0.3 - - -
Vertical 0.2 - - -
5
Horizontal
6.25 250
0.3 - - -
Vertical 0.2 - - -
2.5
Horizontal
3.12 125
0.2 - - -
Vertical 0.2 - - -
