ABUS FU8007 Secvest 2WAY Base Kit Installation - Manual (Page 92)

92
20.4.4 Phone Book
Enter the phone numbers to be dialled.
Press the star key to enter a dial pause. The dial pause is displayed as a comma.
Each dial pause interrupts the dial procedure for 3 seconds. The display can then be
used to enter a name for this number. The alarm centre shows these names in the
phone book so that you can see which destination was used for the message.
20.4.5 SMS Triggers
Select a trigger. For a list of triggers and their attributes, see the table below. A set of
alarm triggers can be connected to each message. “Y” can be entered next to
more than one trigger in the list.
Trigger Meaning
Tamper Transmits an SMS in the event of a tamper alarm.
Alarms Transmits an SMS in the event of an alarm (fire, panic
etc.).
Sets/Unsets Transmits an SMS when the alarm centre is
activated/deactivated.
System Transmits an SMS in the event of a system trigger.
20.4.6 PSTN SMS
If SMS messages should be sent over the PSTN line but no GSM module is attached,
then additional data must be programmed in this menu. It is possible to send SMS
messages over many analogue telephone connections. To do this, the connection
must be authorised and all telecommunications devices between the APL or first TAE
sockets and the alarm system must support the CLIP function.
Select the corresponding function. For a list of functions and their attributes, see the
table below.
Ask your chosen service provider for the protocol used and the SMS service centre
number. Some examples are listed below.
For T-Com (Germany), select protocol TAP8N1 (service centre 01712521001)
For Vodafone (Germany), select protocol UCP8N1 (service centre 01722278800)
For Austria, select protocol TAP7E1 (service centre 0900664914)
For Denmark, select protocol UCP8N1 (service centre 9011201)
For Switzerland, select protocol UCP8N1 (service centre 0794998990)
Function Meaning
Report Type Select the protocol specified by your SMS service centre.
The available options are as follows: TAP 8N1, TAP 7E1,
UCP 8N1 and UCP 7E1.
Service Center
Tel No Enter the provided phone number of the service centre. The
service centre number and protocol must be identical.
Consult the technical support team of the service provider
you wish to use. When asking for the service centre phone
number, also ask which protocol is supported. When
necessary, press the star key to enter a two second pause.
This is displayed as a comma.
Own Tel No Some service centres require the calling number before they
accept a processing request for an SMS. This is also used
for the clear charging of SMS messages. Enter the phone
number of the analogue line here.
