Page 56
56
Select (RF)Output 03
,
for example.
Select SEND to send the learn signal to the receiver.
If the receiver beeps twice, the learn message was correctly received. End the learning
procedure by pressing Yes.
To cancel data entry, press No.
The learn procedure is now started again.
Add another output by pressing Add.
To edit the trained output, press Edit and proceed as detailed in chapter 13.2
(“Editing outputs”).
14.8 WAM outputs
The WAM wireless outputs can be edited after training the WAM as a wireless
transmitter or receiver (function 3).
Select output 31 using the arrow keys (WAM 1).
Edit the menu point under output 31
.
Select the Name menu item.
Please note that the disconnected WAM outputs have a maximum load
of 500 mA at 24 V. This is an opto-isolator with a forward resistance of
2
WAM 1 output 1
Secvest output 31
In the installer menu:
Ж
Ж
Select the Edit Output
menu item.
