90
Select the Trigger menu point.
After Trigger has been confirmed with the Select button, the following graphic display
is shown: (Please note that the home message does not appear. This is always sent
by the alarm centre at the start of every transmission.)
Select a Message where a Trigger should be allocated.
At this point, you link a message with an event (trigger). Select the message to be
programmed. A list of five triggers is then shown on the display. Select a trigger. A list
of available alarm triggers is then shown:
None
Fire Panic
Medical Burg Soak Test Fail
Technical Alarm Social Emergency Social Inactivity
AC Fail Tampers Jamming
Select one of these for this trigger. After selection of the alarm trigger, the list of
triggers is shown again on the display. An alarm trigger can be programmed for each
of the five triggers in the list. When an alarm is selected for each trigger, the alarm
triggers are connected to the triggers and one or more triggers are connected to a
message.
Carry out this assignment for all four messages. After assigning a recorded voice
message to an event (trigger), assign it to one or more phone numbers to be dialled in
the event of an alarm trigger.
20.3.6 Destinations
Select a message where one or more phone numbers should be assigned.
After selecting a message, an overview of the phone numbers entered previously
under “Phone Book” is displayed. If the telephone number has been given a name,
then this is shown in the display instead of the running number.
Select to which of the displayed telephone numbers the voice message should be
sent. Mark phone numbers to be called in the event of an trigger for this voice
message with YES.
20.3.7 Call Acknowledge
Select whether the alarm transmission of the voice message must be confirmed by the
receiver or not.
When the called party answers a call from the voice dialler, they can end the call by
sending back a DTMF “5” (see section 10.10.3.8).
When the “Call Acknowledge” function is activated, the wireless centre ends the call
to this number when it has received a DTMF “5”. When the centre does not receive a
DTMF “5”, then it attempts to make a further call (up to three times).
When the “Call Acknowledge” function is activated, the wireless centre ends further
call attempts to this number as soon as it determines that a call is answered (i.e.
when the receiver has answered). The called party can use DTMF “5” to end the call.
Please note that the wireless centre now calls all other programmed numbers on the
voice dialler after receiving a DTMF “5”.
To prevent calls to other programmed numbers on the voice dialler, the called party
can confirm a call by sending back a DTMF “9”. The wireless centre stops all further
call attempts after receiving the “9” signal.
Five voice messages are available in total. The home message is
always transmitted first by the alarm centre. The alarm centre then
transmits message 1, 2, 3 or 4 to the selected phone number.
Please also note the instructions in the operating manual, section 18.7.
Additional Facilities - Zone Name Prompts
The telephone numbers 1 to 4 are called in the following sequence:
1-2-3-4--1-2-3-4--1-2-3-4
If all the numbers have not been configured, the processing follows an
analogous sequence.
