15
Detector list
When using the smoke detector, press the test button and hold it until the alarm
sounds (about 10 seconds). Press the wall break contact on the opening detector.
The Secvest display confirms successful training by showing the display: Detector
assigned to:
Test button
IR LED on
bottom
¾ Now edit Zone 01.
3.1 Assigning the zone name
Use the created detector list for this purpose.
Enter letters and characters via the keypad.
Letter-to-key assignment:
The letters and characters can be selected by pressing the keys several times. The
cursor goes to the next position after around two seconds.
Select the Name menu item.
Delete the existing name (Zone 01) and assign a unique name for the zone (max. 12
characters).
Example: SD for a smoke detector, then the number, location (e.g. CE for the cellar)
and the room (e.g. HR for the heating room). Detector name: SD1-CE-HR
Now train the detector at the furthest possible distance for the range test.
Opening detector Smoke detector
Display of
the signal
strength
Wall break
contact
