54
Letter-to-key assignment:
The letters and characters can be selected by pressing the keys several times. The
cursor goes to the next position after around two seconds.
Confirm the changes by pressing OK .
14.4 Invert output
Whether the relevant output is inverted or operates without being inverted can
be selected here. Select yes or no.
14.5 Selecting the output type
The output properties can be changed here.
Select Type to configure the output. An overview of output types can be found in the
following table.
Type Meaning
Not Used This output is not in use and is never activated. (Exception:
complete power loss).
Local This output is activated on local alarms for the defined siren
duration. Output does not switch in the case of a technical
alarm.
Output does not switch in the case of an alarm with a part
set system, when "System Options --> Siren in PSet -->
Disabled"
E/E Follow This output is activated for the duration of the delay time
(entry/exit delay active). Output does not switch in the case
of the partition type "Silent Set" and "Instant Set" .
Armed Lamp This output is activated as long as one partition is internally
or externally activated.
24 Hour This output is activated if a 24-hour zone triggers an alarm.
Strobe This output is activated for a local alarm and remains active
until the wireless alarm centre is deactivated.
Strobe Set This output is activated for approx. 10 seconds following
successful activation of the wireless alarm centre and is
used for acknowledging activation. The function must also
be activated in the partition menu. This output is also
activated for a local alarm and remains active until the
wireless alarm centre is deactivated.
Pulse Set This output is activated for approx. 1 second following
successful activation of the wireless alarm centre.
Pulse Unset This output is activated for approx. 1 second following
successful deactivation of the wireless alarm centre as well
as for a panic or fire alarm.
Setting Complete This output is activated for approx. 10 seconds following
successful activation of the wireless alarm centre.
Siren P1 - P4 This output is activated on local alarms in the selected
partition for the defined siren duration. Output does not switch
in the case of a technical alarm or panic alarm.
Strobe Set P1 - P4 This output is activated for a local alarm in the selected
partition and remains active until the wireless alarm centre is
deactivated. The output is also activated for 10 seconds
after successful activation of the partition.
Technical This output is activated if a technical zone triggers an alarm.
Medical This output is activated if a medical emergency call is
activated.
Panic This output is activated if a panic alarm is activated.
Fire This output is activated if a fire alarm is activated.
Zone Follow This output follows the state of a zone. An overview of
zones is displayed when this type is selected. Select a
corresponding zone.
This menu can also be used to automatically activate and deactivate the
alarm centre at a defined time. See the following page for more
information (“Manual” output type).
