68
Instant Set The partition is activated immediately. This exit mode is
recommended for activation over remote control or wireless
cylinders.
Silent Set Same as the “Timed Set” exit mode, except that no exit signal
can be heard during the delay time.
As Prtn 1 This option is available for partitions 2, 3 and 4. When this
option is selected, the system uses the same type as for
partition 1.
16.2 Exit delays of the partition
After entering the exit mode for the partition, a delay time must be entered in the
following cases:
Exit mode = Timed Set or
Exit mode = Silent Set
Select the Ext Time menu point.
After Ext Time has been confirmed with the Select button, the following graphic
display is shown:
Select the corresponding exit time,10,20,30,45,60,120sec.
16.3 Entry delays of the partition
The entry delay is defined in the same way as the exit delay. Configure the entry delay
time for each exit mode.
16.4 Activating the partition response
Select the corresponding alarm response for the partition in the event of an alarm with
activated partition or system.
Function Meaning
Local In the event of an alarm, the internal siren and the
(optional) external siren are activated.
External In addition to the activation of the local siren, the alarm is
also transmitted by telephone.
