16.4 Programming Partitions
If you are using a partitioned system then you can use the
following commands for programming the partitions.
1. Use the commands 01 to 16 and X17 to X32 to assign
a partition to each zone.
- each zone belongs to partition A (factory setting).
- Press key A to assign zones to partition A. Use keys
B, C and D to assign zones to the respective partition.
2. Use command 32 to assign control units to partitions.
In the default setting, all control units belong to all
partitions.
3. Programming from exit mode, alarm reaction and exit
time:
Partition A B C D
Exit
mode Com. 39 Com. 62 Com. 72 Com. 76
Alarm
reaction Com. 47 Com. 63 Com. 73 Com. 77
Exit time Com. 44 Com. 65 Com. 75 Com. 79
4. You can assign siren outputs to each partition using
commands 81 to 84.
- Option 18 assigns the output to partition A.
- Option 19 assigns the output to partition B.
- Option 20 assigns the output to partition C.
- Option 21 assigns the output to partition D.
5. Make sure that the main user is instructed on how to
assign individual user codes to partitions.
Command changes for partitioned systems
Some commands provide new functions for partitioned systems and some commands can no longer be used. The following
table gathers together the differences in the programming:
Command Partition System Single System
01-40 zone programming A – D = partitions A – D = sections of locations
28 mask out the status display partition active location active
32 control units and partitions control unit assigned to part.
B no function
39 location/partition A exit mode option 3 and 4 possible option 3 becomes Lockset
option 4 is not possible
47 partition A alarm report function possible no function
60 zone behaviour for internal B (last exit) no function function possible
61 zone behaviour for internal B (entry zone) no function function possible
62 exit mode for internal B options changed
63 alarm behaviour for internal B options changed
70 zone behaviour for internal C (last exit) no function function possible
71 zone behaviour for internal C (entry zone) no function function possible
72 exit mode for internal C options changed
73 alarm behaviour for internal C options changed
76 exit mode for internal D options changed
77 Alarm behaviour for internal D options changed
81, 82, 83, 84 exits 18-21=Siren Partition
