2. The LCD display shows: 185:KsAutoRstOFF
3. Via the keypad, select from the following items
and press:
0
KsAutoRstOFF
The user must manually reset any
triggered zones.
1
KsAutoRstON
The system automatically resets zone
types KM or KF when the user activates
using the key switch.
4. Confirm your input. On the control unit, enter:
.
5. The control unit acknowledges your input with a
double “beep” tone and shows Installer Mode.
186 Number of home „beep“ calls
To change the settings:
1. On the control unit, enter: 186
2. The LCD display shows: 186:HB calls 02
3. Via the keypad, select from the following items
and press:
01-15
HB calls 01-15
Number of calls with report type
home „beep“ (command 103=6)
4. Confirm your input. On the control unit, enter:
.
5. The control unit acknowledges your input with a
double “beep” tone and shows Installer Mode.
191 Fast format channel 1
To change the settings::
1. On the control unit, enter: 191
2. The LCD display shows: 191:Fire
3. Via the keypad, select from the following items
and press:
00 Not Used
01 Fire
02 PA
03 Burglar
04 Open/Close
05 Alarm Abort
06 Technical Alarm
07 Alarm Confirmation
08 RF Low Battery
09 RF Supervision Loss
10 RF Jamming
11 AC Fail
12 Tamper Alarm
13 Open
14 Close
15 Zone Omitted
16 Medical
17 Keybox
18 AntiMask
19 Smoke Detector
20 Comms Acknowledge
21 Battery Fault
22 System Alarm
In a partitioned system
23 Alarm partition A
24 Alarm partition B
25 Alarm partition C
26 Alarm partition D
30 Pulse Set 1
31 Pulse Set 2
32 Pulse Set 3
33 Pulse Set 4
34 Unset 1
35 Unset 2
36 Unset 3
37 Unset 4
