78
UK
143 Contact ID report Rst
To change the settings:
1. On the control unit, enter: 143
2. The LCD display shows: 143:Mode=Bas+Res
3. Via the keypad, select from the following items
and press:
0
Mode=Basic
All reports with numbers as in the „CID
Code“ column apart from those marked
with a # (see appendix, SIA Report
Mode)
1
Mode=Bas+Res
All reports with numbers as in the „CID
Code“ column (see appendix, SIA
Report Mode)
4. Confirm your input. On the control unit, enter:
.
5. The control unit acknowledges your input with a
double “beep” tone and shows Installer Mode.
151 Additional outputs
By using the cable supplied or the optional relay PCB, you
have access to eight further transistor outputs. To change
the setting of output 1:
1. On the control unit, enter: 151
2. The LCD display shows: 151:Fire
3. Via the keypad, select from the following items
and press:
00 Not Used
01 Fire
02 PA
03 Burglar
04 Open / Closed
05 Alarm Abort
06 Technical Alarm
07 Alarm Confirmation
08 RF Low Battery
09 RF Supervision Loss
10 RF Jamming
11 AC Fail
12 Tamper Alarm
13 Open
14 Close
15 Zone Omitted
16 Medical
17 Keybox
18 Anti-Mask
19 Smoke Detector
20 Comms Acknowledge
21 Battery Fault
22 System Alarm
23 Alarm partition A
24 Alarm partition B
25 Alarm partition C
26 Alarm partition D
30 Set 1
31 Set 2
32 Set 3
33 Set 4
34 Unset 1
35 Unset 2
36 Unset 3
37 Unset 4
4. Confirm your input. On the control unit, enter:
.
5. The control unit acknowledges your input with a
double “beep” tone and shows Installer Mode.
152 Additional outputs
Additional output 2
