ABUS AZ4110 LCD Keypad for Terxon SX_MX Installation User Manual
Page 142
38
UK
Alarm behaviour at Internal D (077
n
)
Menu item
Setting
Meaning
077
0 Control
unit
1
Loudspeaker and control
unit
2
Local
Alarm
3
External Alarm (siren and
dialler)
In a partitioned system
0
Control unit
1
Local Alarm
2
External Alarm (control
unit + siren +dialler)
Exit time at Internal D (079
n
)
Menu item
Setting
Meaning
079
1 10
sec
2
20
sec
3
30
sec
4
45
sec
5
60
sec
6
120
sec
Forbikobler door bell (080
n
)
Menu item
Setting
Meaning
080
0
Siren remains off
1
Door bell triggers siren
Behaviour of relay output 1
(081
nn
)
Menu item
Setting
Meaning
081
00 Siren
01
Input/output to follow
02
Active to follow
03 Active
stable
04
Shock sensor reset
05 Walk
test
06
Ready to follow
07 24
hours
08
Flash to follow
09 Fire
reset
10
Siren test (self setting)
11 Active
acknowledgement
12 Active
pulse
1
13
Inactive pulse 1
14 Confirm
alarm
15
Activate all 1
16
Deactivate all 1
17 Alarm
Only in partitioned system:
18
Siren partition A
19
Siren partition B
20
Siren partition C
21
Siren partition D
22
Flash partition A
23
Flash partition B
24
Flash partition C
25
Flash partition D
26 Active
pulse
1
27 Active
pulse
2
28 Active
pulse
3
29 Active
pulse
4
30
pulse 1
31
Inactive pulse 2
32
Inactive pulse 3
33
Inactive pulse 4
34 Fire
35 Panic
Behaviour of relay output 2
(082
nn
)
Menu item
Setting
Meaning
082
See setting
for transistor output 1
Behaviour of Transistor Output 1
(083
nn
)
Menu item
Setting
Meaning
083
See setting
for transistor output 1
Behaviour of Outputs on Burglar Alarm
(085
n
)
Menu item
Setting
Meaning
085
0
Stable to deactivated
1
Reactivate
Additional Entry Delay
(086
n
)
Menu item
Setting
Meaning
086
0 Off
1
On
