Page 146
42
UK
25
Alarm partition C
26
Alarm partition D
30 Active
pulse
1
31 Active
pulse
2
32 Active
pulse
3
33 Active
pulse
4
34
Inactive pulse 1
35
Inactive pulse 2
36
Inactive pulse 3
37
Inactive pulse 4
Behaviour of Additional Switch Output 2
(152
nn
)
Menu item
Setting
Meaning
152
See setting
for switch output 1
Behaviour of Additional Switch Output 3
(153
nn
)
Menu item
Setting
Meaning
153
See setting
for switch output 1
Behaviour of Additional Switch Output 4
(154
nn
)
Menu item
Setting
Meaning
154
See setting
for switch output 1
Behaviour of Additional Switch Output 5
(155
nn
)
Menu item
Setting
Meaning
155
See setting
for switch output 1
Behaviour of Additional Switch Output 6
(156
nn
)
Menu item
Setting
Meaning
156
See setting
for switch output 1
Behaviour of Additional Switch Output 7
(157
nn
)
Menu item
Setting
Meaning
157
See setting
for switch output 1
Behaviour of Additional Switch Output 8
(158
nn
)
Menu item
Setting
Meaning
158
See setting
for switch output 1
Inversion of additional switch outputs
(159
n
)
Menu item
Setting
Meaning
159
0 Not
inverted
(+ve removed)
1
Inverted
(+ve applied)
160-164 are only permissible when 089 is
set to option 1
Time-confirmed alarm (160
nnn
)
Menu item
Setting
Meaning
160
nnn = 000 – 999 minutes
Confirm internal loudspeaker
(161
n
)
Menu item
Setting
Meaning
161
0
LS for unconfirmed alarm
1
LS for confirmed alarm
Confirm external sirens
(162
n
)
Menu item
Setting
Meaning
162
0 Siren
for
unconfirmed
alarm
1
Siren for confirmed alarm
Confirmed alarm during entry
(163
n
)
Menu item
Setting
Meaning
163
0 Never
1
1
zone
2
2
zones
