112
Chapter 3 MEDIA CONTROL
Hor Image Shift
This option specifies the amount to shift an image horizontally left (-) or right
(+) for precise positioning on the label. The actual width of the image is not
affected by this parameter. The allowable range is -1.00 through +1.00 inches
in .01 inch increments.
The factory default value is 0.00 inches.
Orientation
This menu item selects the image orientation to be used when printing the
label.
• Portrait (factory default). Portrait refers to vertical page orientation,
where the height of a page is greater than its width. The top edge of the
image is parallel to the leading edge of the media. The following
illustration is an example, with the operator viewing the front of the printer.
NOTE: Portrait orientation applies to PGL and VGL emulations. This is
regarded as Inverse Portrait using PPI/ZGL.
4 inches
6 inches
FEED
Th e top edge of
the im age is
para llel to the
leadi ng edg e of
th e me dia.
Leading Edge
