Using the Web Interface User Interfaces for the MPS
Web Interface
The TANDBERG MPS is normally controlled
via the web interface, but any authorized user
may schedule meetings on the TANDBERG
MPS by using the TANDBERG Management
Suite (TMS) or the TANDBERG Scheduler.
In this guide we will describe how to use the
web interface of the TANDBERG MPS.
The TANDBERG MPS consists of the
Multipoint Control Unit (MCU), and may also
include optional Gateway functionality.
Note that the Gateway Configuration tab on
the web interface is only visible when the
Gateway option is installed.
SSH and Telnet
The TANDBERG MPS can also be controlled
via SSH or Telnet by using a comprehensive
set of API commands. This enables the
TANDBERG MPS to be controlled by a different
user interface, such as an AMX or Crestron
control systems.

Start a Web browser and enter
the IP address of the MPS.
You can use either http or https,
with https recommended for
administrative access.
The http settings can be
configured after the first login.
See
System Configuration >
Miscellaneous Configuration .

When prompted for login, enter the user
name admin and password,
TANDBERG (default password).

The Overview page is the opening page
and you will see all conferences currently
active on the TANDBERG MPS.
Overview
The Overview page
lets you see informa-
tion about all confer-
ences currently active
on the TANDBERG
MPS.
MCU
Shows all MCU •
conferences
GW*
Shows all Gateway •
calls.
Phone Book
Use Phone Book to:
Add new entry •
Edit existing entry •
Dial out •
Add up to 250 •
single entries
Add up to 16 group •
entries.
System Status
Gives an overview of:
PRI Status •
G.703 Status •
V.35 Status •
Media Board Infor- •
mation
H.323 Status •
SIP Status •
System Informa- •
tion
System Config.
Lets you configure:
H.320 •
PRI •
G.703 •
IP •
Media Board •
Serial V.35 •
H.323 •
SNMP •
SIP •
QoS •
Miscellaneous •
Upgrade •
Language •
XML •
Certificate Mgmt •
Gateway Config.*
Lets you configure:
Dialling Rules •
Settings •
Files •
MCU Configuration
Lets you configure:
Dial In Numbers •
Network Profile •
Conference Tem- •
plate
Files •
* Visible only when a Gate-
way is installed
For further information please see
the document
TANDBERG MPS API
or http://www.tandberg.com .
For the web interface of the TANDBERG MPS
to work properly, make sure you have
set the permission to ‘Allow Scripting’
in the Security Settings in the Web
browser.
