TANDBERG MSE 8350 User Manual
Codian ip gateway
Table of contents
Document Outline
- Table of contents
- General information
- Installing the IP GW blade
- Step one: Install the IP GW blade into the MSE 8000 chassis
- 1 Remove the blade or blanking blade from the slot into which you are going to install the IP GW blade:
- 2 Open both retaining latches on the front of the IP GW blade. When open, a retaining latch is at a 90˚ angle perpendicular to the front of the blade.
- 3 Slide the IP GW blade into the blade slot (as shown in Figure 2) until it stops.
- 4 Simultaneously close both retaining latches on the blade (thereby engaging the connectors at the rear of the blade) to secure in the chassis as shown in Figure 3.
- 5 Using a No.1 Phillips screwdriver, tighten the screws in the retaining latches with a clockwise quarter turn.
- 1 Remove the blade or blanking blade from the slot into which you are going to install the IP GW blade:
- Step two: Connect to Ethernet Ports A and B
- Step one: Install the IP GW blade into the MSE 8000 chassis
- Initial configuration
- Configuring the IP GW blade
- Checking for updates
- 1 Log in to the IP GW blade web interface and go to Status > General.
- 1 Unzip the software release file that you downloaded.
- 2 In the IP GW blade web interface, go to Settings > Upgrade.
- 3 In the Main software image section, click Browse and locate the unzipped file.
- 4 Click Upload software image. The browser begins uploading the file to the IP GW blade, and a new browser window opens to indicate the progress of the upload.
- 5 Click Shut down IP GW, confirm shut down, and restart the IP GW blade.
- Troubleshooting and technical support information
- Using the event log to help solve a problem
- Getting more help
- 1 Refer to the Technical FAQ section of the web site. We keep the Technical FAQ section up to date with the latest information from our technical support team regarding the resolution of customer issues.
- 2 Contact your reseller. Our resellers have a wealth of experience with our products and this is often a quick way of solving a problem.
- 3 If your query remains unsolved, there is a web form in the Support area of the web site that you can complete. Ensure that you provide all the details requested by the form to assist the technical support team in resolving your problem:
- 1 Refer to the Technical FAQ section of the web site. We keep the Technical FAQ section up to date with the latest information from our technical support team regarding the resolution of customer issues.
