Power Supplies
Chassis Power Supply - TANDBERG MPS 800
Power Supply for TANDBERG MPS 800
The TANDBERG MPS 800 is shipped with 2 hot-swappable power units.
They are installed at the back of the chassis.
If the MPS has more than 3 Media Processing Boards the TANDBERG
MPS is shipped with 3 hot-swappable power units.
The power switch/connector is found at the back of the chassis.
Light Emitting Diodes (LEDs)
On the rear side you will find 2 Light Emitting
Diodes (LEDs) for power status on each of the
power supplies:
Power • : Green when in in normal operation
Alarm • : Red indicates power failure
Power
Alarm
Network Interfaces
TANDBERG MPS 800
The TANDBERG MPS 800 has a 9U-19”
rack-mountable chassis that can host
up to 8 Media Processing Boards and 4
Network Interface Cards.
TANDBERG MPS 200
The TANDBERG MPS 200 has 3U-19” rack-
mountable chassis that can host up to 2
Media Processing Boards and 2 Network
Interface Cards.
Front Chassis
The TANDBERG MPS chassis is 19” rack-
mountable. On the front of the chassis is a
Liquid Crystal Display (LCD) for initial con-
figuration and basic system information.
You will also find 4 Light Emitting Diodes
(LEDs) for power status. The backplane
of the chassis is provided with advanced
CompactPCI technology for high speed
communication between the boards. You
will find 3 cooling fans in the lower front of
the chassis.
Rear Chassis MPS 800
The TANDBERG MPS 800 is shipped with
2 hot-swappable power units for configura-
tions of 1 to 3 Media Processing Boards. If
the unit has more than 3 Media Process-
ing Boards the TANDBERG MPS 800 is
equipped with 3 hot-swappable power
units. The power units are installed at the
back of the chassis. You will also find the
power switch/connector at the back of the
chassis.
Rear Chassis MPS 200
The TANDBERG MPS 200 is shipped with 1
power unit integrated in the chassis.
