Chapter 2 System Architecture

Page 2- 18

NEAX2000 IPS

Request For Proposal (RFP) Reference Guide

NDA-24349 Issue 4

Software Keys/Licenses

The NEAX 2000 IPS systems offer both TDM Software Keys and Peer-to-Peer Seat Licenses, which
are designed with modularity in mind. This approach allows customers a greater degree of cost-control
for new installations and for upgrades to features, capacities and software series itself.

Description

Remarks

Generic Program
64 Port Sys Software

Basic Business/Hotel/Motel Features for:
64 LT Ports, 5 T1’s /E1’s, Remote PIM’s, 5 ISDN-PRI DCH’s, 48
ISDN-BRI Trunks.

NEC Customer Software License Agreement Required

Key Keeper (Parent Capacity Option)
Key Keeper (FD)

Floppy Disk that holds selected Key files from below

Capacity Option (used w/Key Keeper)
LT– 64 Port

Expands LT Ports from 64 to 1020 Ports in increments of 64.

CCIS Link (1)
CCIS Link (4)
CCIS Link (8)

Adds support for one CCIS Link
Adds support for four CCIS Link
Adds support for eight CCIS Link

IPT Card (1)
IPT Card (4)
IPT Card (8)

Adds support for one IP trunk card
Adds support for four IP trunk card
Adds support for eight IP trunk card

Event Based CCIS (ECCIS) Key Adds Event Based CCIS capability
Wireless Software Key

Adds Wireless with support of 128 ZT’s and 256 PS’s

Wireless Software Key 8 PS

Adds 8 Wireless ports each key above the initial 256

T1/E1 6 to 10

Expands T1/E1 capacity between 144 to 240 channels

ISDN DCH 5 to 8

Expands capacity between 5 DCH Cards and 8 DCH cards

IP Remote PIM 1 Site License

Adds IP Remote Capability and is required for each Remote Site

D

term

IP Software Seat Licenses

8 Seat License Key

D

term

IP termainls are controlled by the CPU and do not use

digital line cards! Instead they require D

term

IP seat licenses. The

licenses are available in 8 seat increments and are cumulative.
For example, if you have 8 existing D

term

IP Seats and need a

total of 16, you can simply add another 8-seat license to reach
the total of 16 seats.

Soft-Phone 4 Seat License

Each Soft-Phone 4 Seat License can support up to four
simultaneous sessions via the SP-20 Soft-Phone. The SP20
Soft-Phone also requires IP 8 Seat License. To support eight
simultaneous soft-phone sessions would require eight Soft-
Phone Licenses and 8 IP Seat Licenses.

SP-30 4 Seat License

Each SP-30 4 Seat License can support up to four simultaneous
sessions via the SP-30 Soft-Phone. The SP30 Soft-Phone also
requires IP 8 Seat License. To support eight simultaneous soft-
phone sessions would require eight Soft-Phone Licenses and 8
IP Seat Licenses.
