Chapter 10 System Input/Output (I/O) Interfaces
Page 10-4 NEAX 2000 IPS Request for Proposal (RFP) Reference Guide
NDA-24349, Issue 4
Combinations for Center Office of Centralized Billing
SMDR
Former NEAX 2400 IMS
Format
Extended NEAX 2400 IMS
Format
SMDR with AP00
(PN-AP00-B with AP00 program)
X —
SMDR with AP00
(PN-AP00-B with MRCA program
)
X X
MP built-in SMDR on RS-232C
— —
MP built-in SMDR on IP
X X
X: Available —: Not available
Note: Only one output can be used at the center office.
Combinations for Local Office of Centralized Billing
SMDR
Former NEAX 2400 IMS
Format
Extended NEAX 2400 IMS
Format
SMDR with AP00
(PN-AP00-B with AP00 program)
X —
SMDR with AP00
(PN-AP00-B with MRCA program
)
X —
MP built-in SMDR on RS-232C
X X
MP built-in SMDR on IP
— —
X: Available —: Not available
Note: Only one output can be used at the local office.
Service Conditions
ƒ SMDR can be programmed to record all outgoing calls or toll calls only, depending on the
customers' requirements.
ƒ When customer provided computer equipment is connected using the RS-232C interface, SMDR
information will be transmitted directly to the equipment as each call record is completed.
ƒ If the outgoing call is directed to a trunk, which does not supply answer supervision, SMDR will start
recording the call approximately 10 seconds after the last digit has been dialed.
ƒ Supervision of the status of the external RS-232C terminal is not supplied.
ƒ There are two kinds of SMDR features as follows:
a. Built-in SMDR
The MP card has one of RS-232C ports for SMDR. This card provides memory for a maximum of
1280 calls, and provides a record of a maximum of 256 trunk calls simultaneously for a
maximum of 8-digit extension number.
