Chapter 2 System Architecture
NEAX2000 IPS Request For Proposal (RFP) Reference Guide Page 2-11
NDA-24349 Issue 4
Connection to SMDR is made on a port basis by a front cable
.
Cable for Built-in SMDR/MCI on MP
Name Code Qty Remarks
RS RVS-4S CA-C 1/SMDR RS-232C cable, 4m (13.1ft.)
MP-DTE
RS NORM-4S CA-
A 1/SMDR RS-232C cable, 4m (13.1ft.)
MP-DCE (MODEM)
SMDR (W/AP00)/PMS
Hotel Printer/MCI
CCIS Centralized SMDR
The PN-AP00-B card provides 4 RS-232C interface ports for SMDR, PMS, CIS Printer, Hotel Printer,
MCI and Centralized SMDR. Connection to SMDR, PMS or Printer is made on a port basis by a front
cable.
Cable for AP00
Name Code Qty Remarks
RS RVS-4S CA-C 1/SMDR or
PMS RS-232C cable, 4m (13.1ft.)
PN-AP00 - DTE
RS NORM-4S CA-
A 1/SMDR or
PMS RS-232C cable, 4m (13.1ft.)
PN-AP00 - DCE (MODEM)
RS PRT-15S CA-A 1/Printer RS-232C cable, 15m (49.2ft.)
PN-AP00 - Printer
External Alarm Display
The NEAX 2000 IPS can provide an optional external alarm display unit (ALM DSPP) to indicate
Power-ON/OFF, Major Alarm, and Minor Alarm status
.
External Alarm Display Panel
Name Code Qty Remarks
ALM DSPP 1/System External Alarm Display Panel
Digital Trunk Interface (DTI)
Primary Rate Interface (PRI)
CCIS Trunk Interface (CCT)
The DTI/PRI/CCT connection is available through twisted-pair cable via the MDF
.
