Table 7. A02 WAN I/O Card VPD Part Numbers

Card Name

Feature Code

Part Number

VPD Part Number

1-port E3 I/O card

8501

51H4335

51H4604
(Switzerland)

51H4605 (Sweden)

51H4605 (UK)

51H4606 (New
Zealand)

51H4570

1-port DS3 I/O
card

8502

51H4338

51H4571

1-port OC3 I/O
card (SMF)

8503

51H4558

51H4572

1-port OC3 I/O
card (MMF)

8504

51H4673

51H4852

1-port STM1 I/O
card (SMF)

8505

51H4557

51H4573

1-port STM1 I/O
card (MMF)

8506

51H4674

51H4853

4.8.3 Sample Scenario

The ATM WAN Module is designed to provide high-speed access to the WAN
network for all 8285-attached devices, whether native ATM or connected via the
ATM 4-Port TR/Ethernet Bridge Module.

Figure 29 on page 70 shows some ways the ATM WAN Module can be used with
the 8285.
