If the pinouts are mismatched, the status should be UP-NO ACTIVITY which
means physical activity isn
′
t detected on the port.
•
ATM Connection Parameters
Check if the ATM connection parameters used in the switch and the device
are matched, such as:
−
Connection type (SVC/PVC)
−
VPC/VCC number
−
UNI Version (3.0/3.1/4.0)
−
Service type (CBR/VBR/UBR/ABR)
−
Required and available bandwidth if RB connection
If this information is mismatched, the status should be UP-NOT IN SERVICE
which means physical activity is detected on the port but that the device
cannot access to the network.
7.2.4.2 Check the LANE Registration
When the physical layer connection is established, then the device requests to
register with a LANE network. You can check the status from the IBM 8285
console using SHOW LAN_EMUL SERVERS and SHOW DEVICE commands.
Figure 46 and Figure 47 on page 142 show a sample console screen when the
SHOW LAN_EMUL SERVERS command is issued.
8285> show lan_emul servers 1
1
--------------------------------------------------------------------------
--------------------------- LAN Emulation Server
1 ----------------------
Status
: Running.
LAN type
: Ethernet.
Actual ELAN name
:
″
IBM_ETHERNET_LAN1
″ .
Desired ELAN name
:
″ ″ .
Actual max frame size : 1516.
Desired max frame size: 1516.
ATM address : 39.99.99.99.99.99.99.00.00.99.99.01.09.99.99.99.99.99.01.02
Max number of clients : 64.
Current number of operational clients : 3.
2
Local : 39.99.99.99.99.99.99.00.00.99.99.01.09
99.99.99.99.99.01.00 (port 0.0) OPERATIONAL NonProxy
3
00.20.35.34.20.87.81 (port 1.1) OPERATIONAL NonProxy
3
02.00.88.88.88.88.81 (port 1.8) OPERATIONAL NonProxy
3
8285>
Figure 46. The Sample Console Screen to Check the LANE Registration
Notes:
1
This SHOW LAN_EMUL SERVERS command was issued when the
server was up and the clients have requested to be registered.
2
The number of clients registered with the IBM 8285 integrated LES are
shown on this line.
3
The clients registered with the IBM 8285 integrated LES are shown in
these lines. This information only appears when you specify either of
the servers using the server ID.
