Note
Most of the MES processes, such as installing or removing a module, do not
prevent the others from working. However, the process of adding or
removing the expansion unit to or from the IBM 8285 base unit makes the
ATM subsystem reset.
The install status may be Y even if no module installed. This should be
normal because the IBM 8285 does not clear the previous status. If you
really want to clear the status, use the CLEAR CONFIGURATION command in
maintenance mode.
6.3.3
ATM Concentration Module Basic Configuration Process Steps
The module configuration process is very straight-forward. It summarizes briefly
what operations must be done to install ATM port concentration modules.
However, you should familiarize yourself with the following reference materials
before you begin:
Table 26 (Page 1 of 2). References and Process Quick Guide
Task
References
Physical
Installation
•
8260/8285 ATM 25 Mbps Concentration Module:
Installation and User
′
s Guide, SA33-0383
•
8260/8285 ATM 155 Mbps Flexible Media Module:
Installation and User
′
s Guide, SA33-0358
•
IBM 8260/8285 A4-FB100 Module Installation and User
′
s
Guide, SA33-0324
•
IBM 8260/8285 ATM WAN Module: Installation and User
′
s
Guide, SA33-0396
•
8260/8285 Video Distribution Module: Installation and
User
′
s Guide, GA27-4173
−
Uncrating
−
Installing I/O Cards
−
Installing Module
−
Connecting Cables
Configuration
Process
•
IBM 8260/8285 ATM Command Reference Guide,
SA33-0385
−
SET MODULE
−
SET PORT
−
SET STATIC_ROUTE
−
SET LOGICAL_LINK
−
SAVE ALL|MODULE_PORT
