The commands we will need are:
• SET DEVICE IP_ADDRESS
• SET DEVICE DEFAULT_GATEWAY
• SET DEVICE ARP_SERVER
• SAVE ALL
• SET DEVICE ATM_ADDRESS
• SET PORT
The reason why SAVE ALL precedes SET DEVICE ATM_ADDRESS is that the
latter forces a reset of the ATM subsystem. You will be warned first, but if you
forget to save the parameters you have just entered, they will be lost; only the
ATM address will change.
Below is an annotated transcript of the commands used to configure and test our
simple network.
Table 32 (Page 2 of 2). Necessary Parameters for 8285 #1
Parameter Value Comments
A T M ESI 999999999901 6-byte MAC address.
A T M Selector 00 Has significance only to local
workstation. Should be set to
00.
ARP S e r v e r
ESI 08005A99029F 6-byte MAC address.
ARP S e r v e r
Selector 00 Must explicitly match the ARP
s e r v e r
′ s value.
