VPI 4 and VCI 10 values are used.
−
UNI signalling is set.
−
Flow control is disabled.
−
ILMI handshaking is disabled, forcing UNI 3.1 signalling.
8285> set port 3.2 disable
8285> set port 3.2 enable vpi_vci:4.10 uni flow_control:off ilmi:off_sig_3_1
• Configure one PVC between the VDM port and the video source port, either
local or remote, using the SET PVC command:
SET PVC local_slot.port pvc_id remote_slot.port remote_hub_number path_type
local_vpi remote_vpi bw_alloc bandwidth
local_slot.port The slot and port number for a local end of the PVC.
pvc_id This allows you to define multiple PVCs per port.
remote_slot.port The slot and port number for the other end of the PVC.
remote_hub_number
The hub number (13th byte of the ATM address) of the
other hub. Can match the local hub number for local
PVCs.
path_type Specifies the type of virtual path connection.
local_vpi The vp.vc value for the local end of the PVC. See
Table 5 for allowable values.
remote_vpi The vp.vc value for the other end of the PVC. See
Table 5 for allowable values.
bw_alloc The bandwidth allocation algorithm to be used:
− BEST_EFFORT
− RESERVED_BANDWIDTH
bandwidth The amount of bandwidth to allocate, if bw_alloc has
been set to RESERVED_BANDWIDTH.
With the following command, the video source, an IBM 8300 Video Access
Node is directly connected to the 155 Mbps port on the base unit.
8285>set pvc 1.13 1 3.2 02 channel 0.33 0.33 best-effort
Table 5. VC Values by Port for VDM M o d u l e ( V P = 0 )
Port First Second Third Fourth Fifth Sixth Seventh Eighth
VC
Value
32 33 34 35 36 37 38 39
