M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Per-Port Static VLAN Options Per Port
“unknown
VLAN” (GVRP)
configuration
Tagged or Untagged Auto Forbid
Learn Generate advertisements.
Forward advertisements
for other VLANs
Receive advertisements
and dynamically join any
advertised VLAN Receive
advertisements and
dynamically join any
advertised VLAN that
has the same VID as
the static VLAN Do not allow the
port to become a
member of this
VLAN
Block Generate advertisements
Forward advertisements
received from other ports
to other VLANs
Do not dynamically join
any advertised VLAN Receive
advertisements and
dynamically join any
advertised VLAN that
has the same VID Do not allow the
VLAN on this
port
Disable Ignore GVRP and drop
all GVRP advertisements Ignore GVRP and
drop all GVRP
advertisements Do not allow the
VLAN on this
port
F
IGURE
126 – GVRP options
As the above table indicates a port that has a tagged or untagged static VLAN has the option to
both generate advertisements and dynamically join other VLANs.
The unknown VLAN parameters are configured on a per interface basis using the
CLI. The tagged, untagged, Auto, and Forbid options are configured in the
VLAN context. Since dynamic VLANs operate as tagged VLANs, and it is
possible that a tagged port on one device may not communicate with an
untagged port on another device, GarrettCom Inc. recommends that you use
Tagged VLANs for the static VLANs.
A dynamic VLAN continues to exist on a port for as long as the port continues to receive
advertisements of that VLAN from another device connected to that port or until you:
• Convert the VLAN to a static VLAN
• Reconfigure the port to Block or Disable
• Disable GVRP
• Reboot the switch
The time-to-live for dynamic VLANs is 10 seconds. That is, if a port has not received an
advertisement for an existing dynamic VLAN during the last 10 seconds, the port removes itself
from that dynamic VLAN.
