M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
VLAN Configuration
Syntax configure vlan type=port OR
Syntax vlan type=port
Adding VLANs
Syntax add id= [name=] port=
[forbid=] []
Disabling Management on VLAN
Use the option when creating a VLAN as shown in the add command above.
Starting VLANs
Syntax start vlan=
Saving the configuration
Syntax save
Editing VLANs
Syntax edit id= [name=] port=
[]
Displaying the VLAN information
Syntax show vlan type= []
Magnum6K25#
vlan type=port
Magnum6K25(port-vlan)##
add id=2 name=test port=1-10
Magnum6K25(port-vlan)##
start vlan=all
Magnum6K25(port-vlan)##
save
Saving current configuration...
Configuration saved
F IGURE 70 – configuring VLANs on Magnum 6K switch
The example below shows how to add three different VLANs. Along with the VLANs, Port 14 is
assigned to the four VLANs – the three new ones added plus the DEFAULT-VLAN 1. The following
