M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Syntax rstp - Start (Enable) or stop (Disable) STP
Syntax set stp type= - set the spanning tree protocol to be IEEE 802.1w (Rapid
Spanning Tree Protocol)
Syntax show active-stp – Display which version of STP is currently active
Syntax show rs-ring – show the status of RS-Ring status and configuration
Syntax rs-ring - enable or disable RS-Ring capabilities
Syntax rs-ring add port= - define ports which make up the RS-Ring ports. Note as
discussed earlier, you can create multiple RS-rings on a switch
Syntax rs-ring del port= - remove the switch from RS-Ring topology by eliminating the
end ports on the switch
Magnum 6K25#
authorize s-ring key=BABABABABABAB
S-RING Module Successfully Authorized
Please Save Configuration.
Magnum 6K25#
save
Saving current configuration
Configuration saved
Saving current event logs
Event logs saved
Magnum 6K25#
show rs-ring
RS-RING status : Disabled
RS-RING set on ports : NONE
Magnum 6K25#
show active-stp
Current Active Mode: RSTP.
RSTP is Disabled.
Magnum 6K25#
rstp
Magnum 6K25(rstp)##
rstp enable
Successfully set the RSTP status
Magnum 6K25(rstp)##
show active-stp
Current Active Mode: RSTP.
RSTP is Enabled.
Magnum 6K25(rstp)##
rs-ring add port=13,14
Added Ports: 13,14
Magnum 6K25(rstp)##
show rs-ring
RS-RING status : Disabled
RS-RING set on ports : 13,14
