M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
11 | UNTAGGED | DOWN
12 | UNTAGGED | DOWN
13 | UNTAGGED | UP
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
Magnum6K25#
vlan type=tag
Magnum6K25(tag-vlan)##
add id=10 name=mkt port=14-16
Tag based vlan Added Successfully.
Vlan id :10
Vlan name : mkt
Ports :14-16
Magnum6K25(tag-vlan)##
edit id=10 name=engineering port=14-16
Tag based vlan edited Successfully.
Vlan id : 10
Vlan name : engineering
Ports : 14-16
Magnum6K25(tag-vlan)##
add id=20 name=sales port=14-16
Tag based vlan Added Successfully.
Vlan id :20
Vlan name : sales
Ports :14-16
Magnum6K25(tag-vlan)##
add id=20 name=marketing port=14-16
ERROR: Duplicate Vlan Id
Magnum6K25(tag-vlan)##
add id=30 name=marketing port=14-16
Tag based vlan Added Successfully.
Vlan id :30
Vlan name : marketing
Ports :14-16
Magnum6K25(tag-vlan)##
show vlan type=tag
VLAN ID: 1
Name : Default VLAN
Status : Active
-----------------------------------------------------
PORT |
MODE | STATUS
-----------------------------------------------------
9
| UNTAGGED | UP
10 | UNTAGGED | DOWN
11 | UNTAGGED | DOWN
The edit command can be used to reset the names or
other values
Intentionally done to show the effect of adding a
duplicate VLAN.
Note – ports 14-16 are “DOWN” – the
VLAN configuration is preferably done before
devices are plugged in to avoid connectivity
repercussions.
114
