M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Magnum 6K25(rstp)##
rs-ring enable
RS-RING enabled.
Magnum 6K25(rstp)##
show rs-ring
RS-RING status : Enabled
RS-RING set on ports : 13,14
Magnum 6K25(rstp)##
rs-ring disable
RS-RING disabled.
Magnum 6K25(rstp)##
rs-ring del port=13,14
Deleted Ports: 13,14
Magnum 6K25(rstp)##
show rs-ring
RS-RING status : Disabled
RS-RING set on ports : NONE
Magnum 6K25(rstp)##
exit
Magnum 6K25#
F
IGURE
92 – RS-Ring configuration commands
List of commands in this chapter
Syntax authorize key= - activate the S-Ring capabilities. Don’t forget
to use the “save” command to save the key
Syntax stp – STP Configuration mode
Syntax stp - Start (Enable) or stop (Disable) STP
Syntax set stp type= - set the spanning tree protocol to be IEEE 802.1d or 802.1w
(Spanning Tree Protocol or Rapid Spanning Tree Protocol)
Syntax show active-stp – Display which version of STP is currently active
Syntax show s-ring – show the status of S-Ring status and configuration
Syntax s-ring - enable or disable S-Ring capabilities
Syntax s-ring learn – start the learning process to discover the ring and the ports which make up the S-
Ring
Syntax s-ring add port= - define ports which make up the S-ring ports. Note as
discussed earlier, you can create multiple S-Rings on a switch
166
