M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Magnum 6K25(tag-vlan)##
add id=5 name=engineering port=10-14
Tag based vlan Added Successfully.
Vlan id :5
Vlan name : engineering
Ports :10-14
Magnum 6K25(tag-vlan)##
add id=10 name=marketing port=15,16 nomgt
Tag based vlan Added Successfully.
Vlan id :10
Vlan name : marketing
Ports :15,16
Magnum 6K25(tag-vlan)##
show vlan type=tag
VLAN ID: 1
Name : Default VL
Status : Active
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
1 | UNTAGGED | UP
2 | UNTAGGED | DOWN
3 | UNTAGGED | DOWN
4 | UNTAGGED | DOWN
5 | UNTAGGED | DOWN
6 | UNTAGGED | DOWN
7 | UNTAGGED | DOWN
8 | UNTAGGED | DOWN
9 | UNTAGGED | DOWN
10 | UNTAGGED | DOWN
11 | UNTAGGED | DOWN
12 | UNTAGGED | DOWN
13 | UNTAGGED | DOWN
14 | UNTAGGED | DOWN
15 | UNTAGGED | DOWN
16 | UNTAGGED | DOWN
VLAN ID: 5
Name : engineering
Status : Pending
-----------------------------------------------
PORT | MODE | STATUS
-----------------------------------------------
10 | UNTAGGED | DOWN
11 | UNTAGGED | DOWN
12 | UNTAGGED | DOWN
13 | UNTAGGED | DOWN
14 | UNTAGGED | DOWN
VLAN ID: 10
