M A G N U M 6 K S W I T C H E S , M N S - 6 K U S E R G U I D E
Magnum6K25(stp)##
show stp config
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global)
: YES
Spanning Tree Enabled(Ports) : YES, 9,10,11,12,13,14,15,16
Protocol : Normal STP
Bridge ID : 80:00:00:20:06:25:ed:80
Bridge Priority : 15535
Bridge Forward Delay : 15
Bridge Hello Time : 2
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:80
Designated Root Priority : 15535
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 2
Root Bridge Max Age : 20
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : NO
Magnum6K25(stp)##
timers forward-delay=20 hello=5 age=40
ERROR: Invalid Values
Max Age <= (2*(Forward-Delay-1)) and Max Age >= (2*(Hello-Time+1))
Magnum6K25(stp)##
timers forward-delay=20 hello=5 age=30
Successfully set the bridge time parameters
Magnum6K25(stp)##
show stp config
STP CONFIGURATION
-----------------
Spanning Tree Enabled(Global)
: YES
Spanning Tree Enabled(Ports) : YES, 9,10,11,12,13,14,15,16
Protocol : Normal STP
Bridge ID : 80:00:00:20:06:25:ed:80
Bridge Priority : 15535
Bridge Forward Delay : 20
Bridge Hello Time : 5
Bridge Max Age : 30
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:25:ed:80
Designated Root Priority : 15535
Root Bridge Forward Delay : 20
Root Bridge Hello Time : 5
Root Bridge Max Age : 30
The age parameter is out of range as per
IEEE 802.1d specifications.
