27 R5912621 /01 PDS–4K
5. Outputs
- Model 1 has four HDMI 2.0 output connectors
- Model 2 has four HDMI 2.0 and four 12G-SDI output connectors
6. MVR (Multiviewer)
Both models have one HDMI 2.0 MVR output connector.
Specifications of input and output video connections
On the system’s rear panel, each of the input and output connectors map to a corresponding Source or Take
button on the front panel.
HDMI specifications
• HDMI per 2.0 specification
• Pixel clock up to 600 MHz
-
Max pixel clock at 24 bits/pixel = 600 Mpix/sec
- Max pixel clock at 30 bits/pixel = 480 Mpix/sec
- Max pixel clock at 36 bits/pixel = 400 Mpix/sec
• Supported formats:
-
Formats from as low as [email protected] up to 2560x1600@60 and 3840x1200@60 (30 bits)
- 4K/UHD supported:
◦
3840x2400/ 50/59.94/60 input via 1x HDMI
◦ 3840x2160/ 50/59.94/60 input via 1x HDMI
• EDID version 1.3 compatible
• HDCP version 1.4 and version 2.2 compatible
SDI specifications
• Supported formats:
Signal type Standard Examples
HD SMPTE 292M 1920x1080i @ 50/59.54
1920x1080p @ 23.98/24/25/29.97/30
3G SMPTE 424M
Barcolink 1920x1080p @ 50/59.94/60
1920x1200p @ 50/59.94/60
6G SMPTE 2081-10 3840x2160p @ 23.98/24/25/29.97/30
12G SMPTE 2082-10
Barcolink Ultra 3840x2160 @ 50/59.94/60
3840x2400p @ 50/59.94/60
4.3 PDS-4K DisplayPort 1.2 Input and Audio Card
About the PDS-4K DisplayPort 1.2 Input and Audio Card
The PDS-4K DisplayPort 1.2 Input and Audio Card can be installed into the option slot on the rear of the PDS-
4K for added functionality as long as firmware version 9.0.4876 (or higher) is installed on the unit. This card
allows embedded audio to pass through from the inputs to the program outputs as well as disembed the audio
to Dante®. Audio from Dante® may be embedded onto the program outputs via the Dante® Controller
Software running on a computer attached to the audio network..
Hardware Orientation
