R5912621 /01 PDS–4K 18
PVW (Preview)
Shown in the MVR, a look-ahead for what will be transitioned next.
Source
Source is the input file that has sizing, color, and other settings needed to properly set up the scaler to display
the source based on user input.
3.4 Unpacking and inspection
General
Before shipment, all the devices were inspected and found to be free of mechanical and electrical defects. As
soon as the devices are unpacked, inspect for any damage that may have occurred in transit. Save all packing
material until the inspection is completed. If damage is found, file claim with carrier immediately. The Barco
Sales and the Service office should be notified as soon as possible.
Unpacking
At delivery, all devices are packed in a shipping case. Place the shipping case of the device on a stable (solid),
flat and insulated support during all the unpacking. Open the case from the top. Remove the device that is
packaged in an antistatic bag. Check the box content after unpacking.
After unpacking let the device acclimate to the room temperature which must be higher than 0°C
(32°F) and lower than 40°C (104°F). Neglecting this may result in startup failure of the device.
When shipping a PDS–4K presentation switcher in a Barco-supplied case, make sure that the rear
connector protectors are installed to prevent damage.
Save the original shipping case and packing material, these will be necessary if you ever have to
ship your device. For maximum protection, repack your device as it was originally packed at the
factory.
Box content
After unpacking a PDS– 4K device, it is recommended that it be checked to see if all accessories were
included. The following accessories should be included.
Product Contains Accessories included
R9009650 or
R9009651
PDS–4K Chassis
PDS–4K HDMI Only and
PDS–4K HDMI & SDI
• 1x 14-9750004-90 • European Power Cord CEE7 (not included with units shipped
to China)
• 1x B1959864 • US Power Cord NEMA 5/15 (not included with units shipped
to China)
• 1x B1959865 • China Power Cord GB 2099 (only included with units shipped
to China)
• R9871179 • ImagePRO–II rear rack support
• 2x 09-1802019-90 • Rack ears, PDS–4K
• 2x 09-1802021-90 • Rear connector protectors
• 4x 13-0211010-90 • SCW PN HD 8-32 X .31 BLK screws for rack ears and rear
connector protectors (1x per rack ear and 1x per protector)
• 4x B366920 • Rubber feet
