R5912621 /01 PDS–4K

208

getFrameSettings

Definition:
-

This API shows system information, including all the frames information.

Request:
-

params:

{}

Response:
-

{"System":{"id":0,"Name":"System1","FrameCollection":{"id":0,"Frame":

{"id":"00:0c:29:0e:86:d4","Name":"E2","Contact":"","Version":"4.2.30738",

"OSVersion":"NA","FrameType":0,"FrameTypeName":"E2","Enet":{"DhcpMode":0,

"DhcpModeName":"Static","IP":"10.98.0.165","StaticIP":"192.168.000.175",

"MacAddress":"00:0c:29:0e:86:d4","StaticMask":"255.255.255.000",

"StaticGateway":"192.168.000.001"},"SysCard":{"SlotState":2,

"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":80,

"CardTypeLabel":"System","CardID":0},"Slot":[{"Card":{"CardStatusID":2,

"CardStatusLabel":"Ready","CardTypeID":70,"CardTypeLabel":"Expansion",

"CardID":"thisissometextforid0"}},{"Card":
{"CardStatusID":2,"CardStatusLabel":

"Ready","CardTypeID":70,"CardTypeLabel":"Expansion","CardID":

"thisissometextforid1"}},{"Card":{"CardStatusID":0,"CardStatusLabel":

"Not Installed","CardTypeID":255,"CardTypeLabel":"Unknown","CardID":

"Undefined"}},{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready",

"CardTypeID":1,"CardTypeLabel":"SDI
Input","CardID":"thisissometextforid211"}},

{"Card":
{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":3,"CardID":

"thisissometextforid2"}},{"Card":
{"CardStatusID":2,"CardStatusLabel":"Ready",

"CardTypeID":0,"CardTypeLabel":"DVI
Input","CardID":"thisissometextforid4"}},

{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":2,

"CardTypeLabel":"HDMI/DP Input","CardID":"thisissometextforid5"}},

{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":2,

"CardTypeLabel":"HDMI/DP Input","CardID":"thisissometextforid7"}},

{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":2,

"CardTypeLabel":"HDMI/DP Input","CardID":"thisissometextforid8"}},

{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":2,

"CardTypeLabel":"HDMI/DP Input","CardID":"thisissometextforid9"}},

{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":22,

"CardTypeLabel":"HDMI Output","CardID":"CardID3"}},{"Card":
{"CardStatusID":2,

"CardStatusLabel":"Ready","CardTypeID":22,"CardTypeLabel":"HDMI Output",

"CardID":"CardID4"}},{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready",

"CardTypeID":21,"CardTypeLabel":"SDI Output","CardID":"CardID415"}},

{"Card":{"CardStatusID":2,"CardStatusLabel":"Ready","CardTypeID":40,

"CardTypeLabel":"MVR","CardID":"CardID15"}},{"Card":{"CardStatusID":2,

"CardStatusLabel":"Ready","CardTypeID":50,"CardTypeLabel":"VPU Scaler",

"CardID":"thisissometextforid501"}},{"Card":{"CardStatusID":2,

"CardStatusLabel":"Ready","CardTypeID":50,"CardTypeLabel":"VPU Scaler",

"CardID":"thisissometextforid502"}},{"Card":{"CardStatusID":2,

"CardStatusLabel":"Ready","CardTypeID":50,"CardTypeLabel":"VPU Scaler",

"CardID":"thisissometextforid503"}},{"Card":{"CardStatusID":2,

"CardStatusLabel":"Ready","CardTypeID":50,"CardTypeLabel":"VPU Scaler",

"CardID":"thisissometextforid504"}},{"Card":{"CardStatusID":0,

"CardStatusLabel":"Not Installed","CardTypeID":255,"CardTypeLabel":

Remote Control Protocol
