R5912621 /01 PDS–4K 194
A.1 Specifications of PDS–4K
PDS–4K: Model 1: HDMI - specifications
Input connectors 6x HDMI 2.0
DP + Audio option card Option card slot for adding audio (de)embedding, passthrough and
DisplayPort.
•
2x DisplayPort 1.2 Input connectors
• 2x RJ45 Ethernet jacks for Dante® network audio
Output connectors • 4x HDMI 2.0
• 1x MVR (HDMI 2.0)
Composition & switching • Two (2) non-mixing PIPs per output
• Seamless switching between sources and layouts
• Ultra-low latency (< 2 frames @ 60Hz)
Control • Front-panel button interface
• EM Toolset (PC, MAC OS)
Dimensions • Height: 2.605” (66.2mm) – without feet
• Width: 19.06” (484.1mm) – Rack ear to Rack Ear
• Depth: 16.1 Inches (409mm) – front of knob to back of connector
protectors
Weight 13.7 Lbs. (6.21Kg) – without option card
Warranty 3 years parts and labor
Environmental temperature 0°–40° C (32°–104° F)
Environmental humidity 0–95% Non-Condensing
PDS–4K: Model 2: HDMI + SDI - specifications
Input connectors • 6x HDMI 2.0
• 2x 12G-SDI
DP + Audio option card Option card slot for adding audio (de)embedding, passthrough and
DisplayPort.
•
2x DisplayPort 1.2 Input connectors
• 2x RJ45 Ethernet jacks for Dante® network audio
Output connectors • 4x HDMI 2.0
• 4x 12G-SDI
• 1x MVR (HDMI 2.0)
Composition & switching • Two (2) non-mixing PIPs per output
• Seamless switching between sources and layouts
• Ultra-low latency (< 2 frames @ 60Hz)
Control • Front-panel button interface
• EM Toolset (PC, MAC OS)
Dimensions • Height: 2.605” (66.2mm) – without feet
• Width: 19.06” (484.1mm) – Rack ear to Rack Ear
• Depth: 16.1 Inches (409mm) – front of knob to back of connector
protectors
Weight 13.7 Lbs. (6.21Kg) – with SDI Mezzanines, without option card
Warranty 3 years parts and labor
