R5912621 /01 PDS–4K
206
-
{"params": {"type": 2}, "method":"activateCue", "id":"1234", "jsonrpc":"2.0"}
//Stop – type 2
activateDestGroup
•
Definition:
-
Recall a DestGroup on the Event Master processor. User can recall DestGroup with id, DestGroup
serial number, or DestGroup name.
-
Send any one of the parameters to recall DestGroup.
•
Request:
-
params:
{"id": x}
-
params:
{"destGrpSno": x.y}
-
params:
{"destGrName": "GroupName"}
•
Response:
-
response: null
-
success: (0=success, anything else is an error)
•
Example:
-
{"params": {"id": 0}, "method":"activateDestGroup", "id":"1234",
"jsonrpc":"2.0"}
-
{"params": {"destGrpName": "abc" }, "method":"activateDestGroup", "id":"1234",
"jsonrpc":"2.0"}
-
{"params": {"destGrpSno": 1.00}, "method":"activateDestGroup", "id":"1234",
"jsonrpc":"2.0"}
listCues
•
Definition:
-
This API lists all the cues.
•
Request:
-
params:
{}, "method":"listCues", "id":"1234", "jsonrpc":"2.0"}
•
Response:
-
response: Array of cue objects.
-
success: (0=success, anything else is an error)
•
Example:
-
{"params": {}, "method":"listCues", "id":"1234", "jsonrpc":"2.0"}
changeContent
•
Definition:
-
This API changes the content of a screen destination by putting background and layers in it.
•
Request:
-
params:
{"id":0, "Layers": [{"id":0,"ScalingMode":0]}
◦
id—Screen destination index.
◦
scalingMode: 0 = all. 1 = center cut
•
Response:
-
response: null
-
success: (0=success, anything else is an error)
•
Example:
-
{"params":{"id":0,"Layers": [{"id":1, ,"ScalingMode":0, "LastSrcIdx":10,
"Source":{"HPos":0,"VPos":0,"HSize":1122,"VSize":1122},"PvwMode":1,
"PgmMode":0,"Freeze":0}]}, "method":"changeContent", "id":"1234",
"jsonrpc":"2.0"}
-
{"params":{"id":0, "TestPattern" :5 }, "method":"changeContent", "id":"1234",
"jsonrpc":"2.0"}
