Tables and overviews
16.5 Functions of the TNC 320 and the iTNC 530 compared
16
534
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
Function TNC 320 iTNC 530
SLII Cycles 20 to 24:
Handling of islands which are
not contained in pockets Cannot be defined with
complex contour formula Restricted definition in complex
contour formula is possible
Set operations for SL cycles
with complex contour formulas Real set operation possible Only restricted performance of
real set operation possible
Radius compensation is active
during
CYCL CALL
Error message is issued Radius compensation is
canceled, program is executed
Paraxial positioning blocks in
contour subprogram Error message is issued Program is executed
Miscellaneous functions
M in
contour subprogram
Error message is issued M functions are ignored
M110 (feed-rate reduction for
inside corner)
Function does not work within
SL cycles Function also works within SL
cycles
SLII Contour Train Cycle 25:
APPR/DEP blocks in contour
definition Not allowed, machining of closed
contours is more coherent
APPR/DEP blocks are allowed as
contour elements
General cylinder surface
machining :
Contour definition With X/Y coordinates,
independent of machine type Machine-dependent, with
existing rotary axes
Offset definition on cylinder
surface With datum shift in X/Y,
independent of machine type Machine-dependent datum
shift in rotary axes
Offset definition for basic
rotation Function available Function not available
Circle programming with C/CC Function available Function not available
APPR/DEP blocks in contour
definition
Function not available Function available
Cylinder surface machining with
Cycle 28:
Complete roughing-out of slot Function available Function not available
Definable tolerance Function available Function available
Cylinder surface machining with
Cycle 29
Direct plunging to contour of
ridge Circular approach to contour of
ridge
Cycles 25x for pockets, studs
and slots:
Plunging movements In limit ranges (geometrical
conditions of tool/contour)
error messages are triggered
if plunging movements lead to
unreasonable/critical behavior In limit ranges (geometrical
conditions of tool/contour),
vertical plunging is used if
required
