Calculation of circles 8.5
8
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
243
8.5 Calculation of circles
Application
The TNC can use the functions for calculating circles to calculate
the circle center and the circle radius from three or four given
points on the circle. The calculation is more accurate if four points
are used.
Application: These functions can be used if you wish to determine
the location and size of a hole or a pitch circle using the
programmable probing function.
Function Soft key
FN23: Determining the CIRCLE DATA from three
points
e.g.
FN 23: Q20 = CDATA Q30
The coordinate pairs of three points on a circle must be saved in
Q30 and the following five parameters—in this case, up to Q35.
The TNC then saves the circle center in the reference axis (X if
spindle axis is Z) in parameter Q20, the circle center in the minor
axis (Y if spindle axis is Z) in parameter Q21, and the circle radius in
parameter Q22.
Function Soft key
FN24: Determining the CIRCLE DATA from four
points
e.g.
FN 24: Q20 = CDATA Q30
The coordinate pairs of four points on a circle must be saved in Q30
and the following seven parameters—in this case, up to Q37.
The TNC then saves the circle center in the reference axis (X if
spindle axis is Z) in parameter Q20, the circle center in the minor
axis (Y if spindle axis is Z) in parameter Q21, and the circle radius in
parameter Q22.
Note that
FN 23 and FN 24 automatically overwrite
the resulting parameter and the two following
parameters.
