Functions of the TNC 320 and the iTNC 530 compared 16.5
16
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
523
Comparison: Touch probe cycles in the Manual
Operation and El. Handwheel modes
Cycle TNC 320 iTNC 530
Touch-probe table for managing 3-D touch probes X –
Calibrating the effective length X X
Calibrating the effective radius X X
Measuring a basic rotation using a line X X
Set the datum in any axis X X
Setting a corner as datum X X
Setting a circle center as datum X X
Setting a center line as datum X X
Measuring a basic rotation using two holes/cylindrical studs X X
Setting the datum using four holes/cylindrical studs X X
Setting the circle center using three holes/cylindrical studs X X
Support of mechanical touch probes by manually capturing the current
position By soft key By hard key
Writing measured values in preset table X X
Writing measured values in datum tables X X
Comparison: Touch probe cycles for automatic
workpiece inspection
Cycle TNC 320 iTNC 530
0, reference plane X X
1, polar datum X X
2, calibrating TS – X
3, measuring X X
4, measuring in 3-D – X
9, calibrating TS length – X
30, calibrating TT X X
31, measuring tool length X X
32, measuring tool radius X X
33, measuring tool length and radius X X
400, basic rotation X X
401, basic rotation from two holes X X
402, basic rotation from two studs X X
403, compensating a basic rotation via a rotary axis X X
404, setting a basic rotation X X
405, compensating workpiece misalignment by rotating the C axis X X
408, slot center datum X X
409, ridge center datum X X
410, datum from inside of rectangle X X
