Setting up data interfaces 15.8
15
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
475
Data transfer between the TNC and TNCremoNT
Before you transfer a program from the TNC to the
PC, you must make absolutely sure that you have
already saved the program currently selected on the
TNC. The TNC saves changes automatically when
you switch the mode of operation on the TNC, or
when you select the file manager via the PGM MGT
key.
Check whether the TNC is connected to the correct serial port on
your PC or to the network.
Once you have started TNCremoNT, you will see a list of all files
that are stored in the active directory in the upper section of the
main window
1 . Using , , you can select
any drive or another directory on your PC.
If you want to control data transfer from the PC, establish the
connection with your PC in the following manner:
Select , . TNCremoNT now receives
the file and directory structure from the TNC and displays this at
the bottom left of the main window
2
To transfer a file from the TNC to the PC, select the file in
the TNC window with a mouse click and drag and drop the
highlighted file into the PC window
1
To transfer a file from the PC to the TNC, select the file in
the PC window with a mouse click and drag and drop the
highlighted file into the TNC window
2
If you want to control data transfer from the TNC, establish the
connection with your PC in the following manner:
Select , . TNCremoNT is now in server
mode. It can receive data from the TNC and send data to the
TNC
You can now call the file management functions on the TNC
by pressing the key PGM MGTSee "Data transfer to/from
an external data medium", page 110, in order to transfer the
desired files
Exiting TNCremoNT
Select ,
Refer also to the TNCremoNT context-sensitive help
texts where all of the functions are explained in more
detail. The help texts must be called with the F1 key.
