The PLANE Function: Tilting the Working Plane (Software Option 1) 11.2
11
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
367
Positioning the rotary axes in a separate block
Proceed as follows if you want to position the rotary axes in a
separate positioning block (option
STAY selected):
Danger of collision!
Pre-position the tool to a position where there is no
danger of collision with the workpiece (clamping
devices) during positioning.
Select any
PLANE function, and define automatic positioning
with the
STAY option. During program execution the TNC
calculates the position values of the rotary axes present on the
machine, and stores them in the system parameters Q120 (A
axis), Q121 (B axis) and Q122 (C axis)
Define the positioning block with the angular values calculated
by the TNC
NC example blocks: Position a machine with a rotary table C and a tilting table A to a space angle of B+45°
...
12 L Z+250 R0 FMAX
Position at clearance height
13 PLANE SPATIAL SPA+0 SPB+45 SPC+0 STAY
Define and activate the PLANE function
14 L A+Q120 C+Q122 F2000 Position the rotary axis with the values calculated by the
TNC
...
Define machining in the tilted working plane
