16.3 Technical Information
Explanation of symbols
■
Standard
□
Axis option
1 Software option 1
User functions
■
Basic version: 3 axes plus closed-loop spindle
■
Fourth NC axis plus auxiliary axis
■
or
Short description
□
Additional axis for 4 axes plus closed-loop spindle
□
Additional axis for 5 axes plus closed-loop spindle
Program entry In HEIDENHAIN conversational and ISO
■
Nominal positions for lines and arcs in Cartesian coordinates or polar
coordinates Position data
■
Incremental or absolute dimensions
■
Display and entry in mm or inches
■
Tool radius in the working plane and tool length Tool compensation
■
Radius compensated contour look ahead for up to 99 blocks (M120)
Tool tables Multiple tool tables with any number of tools
Constant contour speed
■
With respect to the path of the tool center
■
With respect to the cutting edge
Parallel operation Creating a program with graphical support while another program is being
run
Rotary table machining
(software option 1) 1 Programming of cylindrical contours as if in two axes
1 Feed rate in distance per minute
■
Straight line
■
Chamfer
■
Circular path
■
Circle center
■
Circle radius
Contour elements
■
Tangentially connected arc
■
Corner rounding
Approaching and departing
the contour
■
Via straight line: tangential or perpendicular
■
Via circular arc
FK free contour
programming
■
FK free contour programming in HEIDENHAIN conversational format
with graphic support for workpiece drawings not dimensioned for NC
■
Subprograms Program jumps
■
Program-section repeat
■
Any desired program as subroutine
