Programming: Q Parameters
8.8 Additional functions
8
260
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
Group name, ID no. Number Index Meaning
Values programmed
immediately after TOOL
CALL, 60 1 - Tool number T
2 - Active tool axis
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
3 - Spindle speed S
4 - Oversize for tool length DL
5 - Tool radius oversize DR
6 - Automatic TOOL CALL
0 = Yes, 1 = No
7 - Tool radius oversize DR2
8 - Tool index
9 - Active feed rate
Values programmed
immediately after TOOL
DEF, 61 1 - Tool number T
2 - Length
3 - Radius
4 - Index
5 - Tool data programmed in TOOL DEF
1 = Yes, 0 = No
Active tool compensation,
200 1 1 = without
oversize
2 = with
oversize
3 = with
oversize and
Oversize from
TOOL CALL Active radius
2 1 = without
oversize
2 = with
oversize
3 = with
oversize and
Oversize from
TOOL CALL Active length
3 1 = without
oversize
2 = with
oversize
3 = with
oversize and
Oversize from
TOOL CALL Rounding radius R2
