Programming the first part 1.3
1
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
49
Enter Retract the tool: Press the orange axis key Z
in order to get clear in the tool axis, and enter the
value for the position to be approached, e.g. 250.
Confirm with the ENT key
Confirm
Radius comp.: RL/RR/no comp? by
pressing the ENT key: Do not activate the radius
compensation
Confirm
Feed rate F=? with the ENT key: Move at
rapid traverse (
FMAX)
MISCELLANEOUS FUNCTION M? ENTER M2 to end
the program and confirm with the END key: The
TNC saves the entered positioning block
Further information on this topic
Complete example with NC blocks : See "Example: Linear
movements and chamfers with Cartesian coordinates",
page 191
Creating a new program: See "Opening programs and entering",
page 85
Approaching/departing contours: See " Approaching and
departing a contour", page 174
Programming contours: See "Overview of path functions",
page 182
Programmable feed rates: See "Mögliche Vorschubeingaben"
Tool radius compensation: See "Tool radius compensation",
page 164
Miscellaneous functions (M): See "M functions for program run
inspection, spindle and coolant ", page 307
