Programming: Q Parameters
8.12 Preassigned Q parameters
8
296
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
Coordinates after probing during program run
The parameters Q115 to Q119 contain the coordinates of the
spindle position at the moment of contact during programmed
measurement with the 3-D touch probe. The coordinates refer to
the datum point that is active in the Manual Operation mode.
The length of the stylus and the radius of the ball tip are not
compensated in these coordinates.
Coordinate axis Parameter value
X axis Q115
Y axis Q116
Z axis Q117
4th Axis
Machine-dependent Q118
V. axis
Machine-dependent Q119
Deviation between actual value and nominal value
during automatic tool measurement with the TT 130
Deviation of actual from nominal value Parameter value
Tool length Q115
Tool radius Q116
Tilting the working plane with mathematical angles:
rotary axis coordinates calculated by the TNC
Coordinates Parameter value
A axis Q120
B axis Q121
C axis Q122
